Length
Overall - 119.37 in. (303.2 cm)
Overall - 119.37 in. (303.2 cm)
Height
Overall (with suntop) - 74.02 in. (188 cm)
Overall (without suntop) - 48.54 in. (123.3 cm)
Overall (with suntop) - 74.02 in. (188 cm)
Overall (without suntop) - 48.54 in. (123.3 cm)
Width
Overall - 49.33 in. (125.3 cm)
Overall - 49.33 in. (125.3 cm)
Weight
Dry - 1,031.8 lb. (468 kg)
Dry - 1,031.8 lb. (468 kg)
Ground Clearance
Minimum - 4.52 in. (11.5 cm)
Minimum - 4.52 in. (11.5 cm)
Wheelbase
77.2 in. (196.1 cm)
77.2 in. (196.1 cm)
Turning Radius
Minimum - 13.05 ft. (3.98 m)
Minimum - 13.05 ft. (3.98 m)
Engine
Yamaha-built, low-emission 60° incline OHV
Air cleaner - Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge
Yamaha-built, low-emission 60° incline OHV
Air cleaner - Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge
Displacement
402 cc
402 cc
Fuel System
Electronic Fuel Injection
Electronic Fuel Injection
Starting
Generator with pedal start system
Generator with pedal start system
Lubrication
Splash-style positive oil
Splash-style positive oil
Fuel Capacity
5.2 U.S. gal. (20 l)
5.2 U.S. gal. (20 l)
Oil Capacity
1.16 U.S. qt. (1.1 l, 1,100 cc)
1.16 U.S. qt. (1.1 l, 1,100 cc)
Frame
HybriCore™ chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester / urethane powder topcoat
Body - Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane
HybriCore™ chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester / urethane powder topcoat
Body - Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane
Front Suspension
Tru-Trak II™ fully independent automotive-style strut
Tru-Trak II™ fully independent automotive-style strut
Rear Suspension
Unit swing arm with DUAL RATE coil springs over hydraulic shock absorbers
Unit swing arm with DUAL RATE coil springs over hydraulic shock absorbers
Steering
Self-compensating double reduction helical rack-and-pinion
Self-compensating double reduction helical rack-and-pinion
Speed - Forward
Maximum - 17.5 mph (28 km/h)
Maximum - 17.5 mph (28 km/h)
Speed - Reverse
Maximum - 13 mph (21 km/h)
Maximum - 13 mph (21 km/h)
Seating
Capacity - 2 persons
Color - Black
Suntop color - Black
Capacity - 2 persons
Color - Black
Suntop color - Black
Additional Colors
Bluestone
Carbon
Coral Red
Evergreen
Glacier
Bluestone
Carbon
Coral Red
Evergreen
Glacier
Cargo Box Length
Cargo bed - 41.1 in. (104.4 cm)
Cargo bed - 41.1 in. (104.4 cm)
Cargo Box Height
Cargo bed - 11.9 in. (30.2 cm)
Cargo bed - 11.9 in. (30.2 cm)
Cargo Box Width
Cargo bed - 45.9 in. (30.2 cm)
Cargo bed - 45.9 in. (30.2 cm)
Cargo Box Capacity
Cargo bed - 800 lb.
Cargo bed - 800 lb.
Towing Capacity
1,200 lb.
1,200 lb.
Warranty
Standard 2-year limited vehicle
Standard 2-year limited vehicle
